MD 9272 Leakage Clamp TRMS Meter with Power Functions

MD 9272 is a unique earth leakage clamp meter. It not just has the ability to accurately read the TRMS AC leakage current of a system, it can also detect losses in the system and suggest possible reasons for the loss. The voltage (AC/DC), frequency, power, harmonic, power factor (PF), total  harmonic distortion  (THD) and  crest factor  measurements make  this instrument suitable for any electrician and engineer.


Download Datasheet



SKU: md9272 Category:

Description

TEST FUNCTIONS

  • TRMS AC, DC voltage measurement.
  • TRMS AC current measurement.
  • Frequency measurement.
  • Power parameters measurement.

KEY FEATURES

  • TRMS: accurate measurements on sinusoidal and non-sinusoidal signals.
  • Jaw size: 28 mm.
  • Shielded Jaw: shielded jaw allows the clamp meter to be used in the noisiest environments.
  • Accurate: readings of AC current with an accuracy of 0.8 % and a base resolution of 0.01 mA and voltage with an accuracy of 0.5 % and a base resolution of 0.01 V.
  • Power: measures various power parameters (active, reactive, apparent power, THD, PF, phase displacement).
  • Intelligent  loss  analysis:  complex  algorithms  detect  loss  and  allow  determining  possible reasons for current loss.
  • Harmonics: measures  current  or  voltage  harmonic  components  and  a  percentage  value  of  a harmonic up to the 19th.
  • THD and PF: dual display allows readings to be displayed along with Total Harmonic Distortion (THD) or Power Factor (PF).
  • Peak value: the peak value of the waveform or crest factor can be displayed.
  • MAX/MIN/HOLD  mode: displays maximum, minimum or average measured value.

TECHNICAL DATA

Dimensions (w x h x l): 60 x 43 x 190 mm

Mass (without accessories): 255 g
